      ExtremeCloud IQ / Aerohive integration

      The following article explains how to integrate ExtremeCloud IQ Aerohive with Basking.io in order to enable the location data. This integration allows you to use your existing cloud-managed ExtremeNetworks and Aerohive with Basking.io to provide occupancy analytics for your offices.

      Architecture

      The following diagram explains the general architecture of the integration between ExtremeCloud IQ and Basking.io:

      Basking.io-Architecture-ExtremeCloud-IQ-Aerohive-768x536

      The data integration is performed in the ExtremeCloud IQ portal and consists of a push integration. Basking.io is reading the data that ExtremeCloudIQ is pushing, with no ability to modify the configuration or accessing any other data.

      Requirements for the integration

      The following requirements apply for using the ExtremeCloud IQ/ Aerohive integration with Basking.io:

      a) Hardware Requirements

      1. Cloud-managed Aerohive or ExtremeNetworks Access Points

      b) Organizational Requirements

      1. Admin access to the ExtremeCloud IQ interface
      2. Mapping of APs (Optional, if floor and area-level occupancy analytics is required)

      Steps for integrating ExtremeCloud IQ/ Aerohive with Basking.io

      1. Login to ExtremeCloud IQ

      Please login at https://extremecloudiq.com/login

      Basking_io-ExtremeCloud_IQ_Login-768x903

      Note: If you have different networks, please select the network you wish to connect to Basking.

      2. Navigate to Global Settings

      Click on your username at the top-right corner and enter the global settings.

       Basking_io_ExtremeCloud_IQ_Global_Settings-768x624

      3. Register the Basking.io URL

      In order to register the URL for Basking.io, please open the API/ API Data Management menu and click on the + button.

      Basking_io_ExtremeCloud_IQ_API_Data_Management-1-768x445

      The following mask will open. Please fill in the following elements:

      • Post URL (as provided by the Basking team)
      • Access Token (as provided by the Basking team)
      • Message Type: Client Centric
      • Make sure that the Enable button is activated

      Basking_io_ExtremeCloud_IQ_Add_Presence_and_Location_Data_Feed-1-768x566

      Finally, click on Save.

      4. Update and deploy the network policy

      The last step involves updating the Network policy for the APs in the locations that will be measured by Basking.

      ExtremeCloud_IQ-768x446

      Please execute the following steps:

      • Under Configure, select Network Policies
      • Select the policy you need to update
      • Make sure that Enable Presence Analytics is enabled
      • Save the network policy
      • Finally, deploy the network policy to the APs.

      ExtremeCloud IQ/ Aerohive Technical Documentation



      Please refer to the following technical documents for more information:
